Aviation engineers depend upon Snap-on’s Level 5 tool management system
Aviation engineers depend upon Snap-on’s Level 5 tool management system
Safran Landing Systems are world leaders in the design, manufacture, assembly and testing of aircraft landing gear, steering, and braking systems.
The French company has supplied this vital, safety critical equipment for use on 33,000 aircraft worldwide, including Airbus aircraft from the A320 range through to the larger, long haul A350 and A380.
The company also supplies more than 20 other manufacturers of commercial and military aircraft within the global aviation industry.
Airline passengers place their trust in the skills of experienced flight crews, who in turn depend upon the efficiency and safe operation of the aircraft’s landing gear, braking and steering systems, wheels and tyres. The Airbus A380 has five landing gear assemblies and 22 wheels, which reach almost 200mph before takeoff.
Engineers and technicians working in Safran’s Gloucester production centre recognize the importance of controlling the wide range of specialist hand and power tools they use every day.
They depend upon Snap-on Industrial’s Level 5 Automated Tool Control system which allows the use of any number of networked tool storage cabinets to be monitored from one control desk. Computer software ensures that every tool is constantly tracked, identifying who is using it and in which location. The system verbally announces when a tool is removed or returned to its cabinet.
This high level of vigilance provides vital safeguards against tools being misplaced, with the inherent risk of them causing foreign object damage if they are not returned.
According to Safran engineering managers, tool control has always been a major area of concern, as the company is required to demonstrate effective tool management to meet the stringent requirements of technical audits.
They especially value the Snap-on system’s ability to capture data Via a bank of cameras fitted to every ATC cabinet, providing all the information needed to comply with tool control measures. The flexibility provided to tool users and managers also proves a great advantage.
When switching to the Snap-on system some Safran fitters were uneasy about change, but their confidence was soon restored when they realised how easy it was to find the tools they required without delay.
Safran have also praised the quick and willing response of Snap-on Industrial technical advisers who provide full training and problem-solving services, ensuring that the company obtains maximum benefit from its ATC system.
Says Richard Packham, Director UK & Europe for Snap-on Industrial: “Snap-on’s automated system takes tool management to an entirely new level, giving workshop managers and other authorised users easy access to the tools they need for the job in hand while protecting against foreign object damage.
“The ability to monitor several boxes from one central computer offers managers a huge time saving advantage.”
Snap-on Industrial’s Level 5 automated tool management system minimises the risk of human error, as automated tool control constantly tracks every tool and detects which tools have been removed or returned, ensuring greater protection against FOD.
It also enables aviation and aerospace engineers and technicians to find every tool they need, when they need it, saving time and easing stress.
The system provides complete reports on everything managers or supervisors need to keep an eye on. They are even informed when a tool needs to be refilled or ordered.
Engineered to track individual tools by user automatically, without bar codes, scanners, RFID tags or other add-ons, the system works at the speed its user’s demand. Level 5™ ATC boxes are network ready, using either Ethernet or wireless connection. Powerful software enables users to review activity at all boxes in their location from one central computer, avoiding the need to inspect each box.
Major benefits of the system include:
- No individual tool scanning required.
- No RFID tags to install or replace.
- No camera recognition limitations on tool size, from 1/4” screwdriver bits upwards, if it fits in the box, it can be tracked.
- Intuitive interface, via touchscreen.
- Audible voice confirmation of tool removal and replacement.
- Automatic locking for maximum security.
- Errors announced and displayed to indicate incorrect tool position or advise when a drawer is not closed.
Administrators can view all boxes on the network, on or off-line, and see the status of each box, including the number of tools issued, identify active users, and review all history. System alerts, such as sending e-mails to supervisors, can be customised for lost or broken tools or calibration requirements.
Company Profile
Since 1920 Snap-on Industrial has been a world leading tooling solutions specialist with unrivalled expertise in providing bespoke solutions across a diverse range of industry sectors, which include natural resources, defence, aviation, construction, as well as manufacturing, rail and food production.
Snap-on Industrial provides companies with strategic advantages in addressing the challenge of increasing profitability, through reduced downtime, increased productivity and cost control.
Snap-on Industrial at Farnborough International Airshow 2024
Snap-on Industrial at Farnborough International Airshow 2024
22-26th June 2024 | Hall 2 | Booth 2016
Serving the critical industries since 1920, Snap-on Industrial designs and supplies products and services to their customers, including hand & power tools, tool storage, tool control, information & management systems and other solutions for aviation & aerospace, government & military, rail, energy and education.
Come and see us on stand at the Farnborough International Airshow 2024. We will be showcasing our Level 5 tool management system and torque products as well as various other tools especially picked out for Aviation.
About the event
The apex of aviation – Discover the future of aerospace at the world’s leading airshow.
Every two years, the aerospace, aviation and defence industries are invited to Farnborough International Exhibition & Conference Centre for the world’s best airshow to pioneer change, build new connections, engage with thought leaders and get access to unparalleled business development opportunities.
Farnborough International Airshow 2024 | Hosting leading innovators from the aerospace, aviation and defence industries and beyond
Farnborough International Airshow 2024
Exhibitor: Snap-on Industrial
Hall 2
Booth 2016
22-26th July 2024
Industrial 14.4 V MicroLithium Cordless Drills
Arron Brown
Our NEW Industrial 14.4 V MicroLithium Cordless Drills offer the precision and performance of a pneumatic drill with cordless convenience.
Target Customers include:
- Aerospace and Aviation
- Manufactured Housing & RV
- Metal Fabrication
- Transportation
- Assembly - working in confined areas, more productivity with less fatigue, Mobility
- General MRO - ideal for continuous drilling applications, additional tooling available with 14.4V battery
- Shipbuilding
- Trailer Bodies
- Technical Training and Education
FEATURED
PRODUCT INFORMATION
Purpose Designed
Improves productivity in industrial drilling applications by drilling holes faster than standard cordless drills with more precision and reduced user fatigue.
Performance
- Available in four speeds: 1100, 3200, 4400, and 6300 RPMs
- Drills fast with the proper RPM for the material and hole size
- Drill 3X faster than common cordless drills (3/16″ hole in aluminium)
- Palm grip allows:
- Precise drilling reducing the tendency to drill oval holes
- Comfortable drilling with minimal wrist stress
- Easy access, patented forward/reverse switch located away from the grip solves finger chaffing and accidental bumps
- 2-Stage trigger for easy hole starting:
- First stage is slow to get the hole started
- Second stage is variable to full speed for fast drilling
Features
-
PRECISION 3/8″ CHUCK allows the user to achieve a more precise finished hole
-
4 SPEED OPTIONS to provide the optimal cutting speed for the material and hole size being drilled
-
DIRECTIONAL CONTROL SWITCH placement designed to be out of the grip zone and convenient to use
-
DRILL BODY AND GRIP
-
Designed to maintain perfect hand/drill alignment, achieving superior results
-
Full-comfort grip with integrated finger rest encourages proper grip
-
Pushing in line with drill bit is comfortable and gives a true hole versus pushing below drill bit which results in user fatigue and a crooked hole
-
Drill more holes per battery with the proper drill speed and grip behind the bit.
Example: 50% more 3/16″ holes drilled into 7075 Aluminium with one 2.5 A-hour battery compared to one 5.0 A-hour DIY drill and battery.
Comfort is essential when you are drilling all day long.
Industrial 14.4 V MicroLithium drills are ergonomic to be comfortably used for long periods.
Get precise drilling with proper grip behind the drill bit.
Proper grip and finger alignment helps you achieve consistently better results.
Drill comfortably, repetitively... all day.
21 Piece Jobber Length ThunderBit® High-Speed 135° Split Point Drill Bit Set
DBTB121
- Includes 1/16–3/8″ drill bits in a metal drill index
- Industrial-grade steel with bronze oxide surface treatment
- Bits drill at higher speeds in tougher drilling conditions
- 135° split points for easier drill starting without the need for centre punching
- Heavy-duty web construction for higher strength and less breakage
- Improved chip ejection through specially engineered flute design
14.4 V MicroLithium 2.5 ah Battery
CTB8174
- Works with all Snap-on 14.4 V MicroLithium series tools
- Fast 70-minute charge time
14.4 V MicroLithium Battery Charger
CTC772A
Magnetic Boot
CTLMAG-BOOT
- Easy-on, easy-off twist attachment for 14.4 V MicroLithium cordless battery pack
Snap-on support helps to transform automotive engineering at leading college
Snap-on support helps to transform automotive engineering at leading college.
The Snap-on team take pride in working with excellent UK colleges to pursue a vital mission: developing the knowledge and skills of young people who will become tomorrow’s engineers and technicians.
Our contribution goes far beyond supplying equipment and tools. We’re always pleased to complement the great work of college tutors with our many years’ experience of how essential engineering tasks should be done safely, efficiently and on budget.
At Yeovil College, serving South Somerset plus North and West Dorset, we have transformed the automotive engineering department, supplying and installing state of the art technical equipment and diagnostic systems, to create purpose designed safe, clean and well-lit workspaces.
We began by listening to the department’s leaders so we could really understand what they needed to achieve the college’s ambitious objectives. Snap-On’s Paul Towner has years of experience of working with colleges, so he took responsibility to manage the project.
Challenged by a growing curriculum the department acknowledged that its outdated resources and lack of usable space were restraints to them meeting the demands of providing the latest, highly technical automotive engineering qualifications. These are pushing the boundaries of current education in the automotive sector.
Says Jonathan Andrews, the college’s Curriculum Area Manager, Automotive Engineering: “I would like to extend my sincerest thanks to Paul and the Snap-on UK Team who, along with the vision created by Yeovil College, have delivered nothing short of a transformation.
“Well done to all involved. We look forward to enjoying the resources and space for many more years.”
The integrated improvement package provided by Snap-on updated the automotive engineering workshop with the latest equipment, including ramps, ADAS, four-wheel alignment, diagnostic systems and hand tools. Snap-on then provided intensive technical guidance to ensure that the equipment could be used to maximum benefit.
Giving the workshop a new lease of life was driven in part by the introduction of new ‘T’ level qualifications. Also to enable learners to pursue and gain electric vehicle qualifications to meet rapidly growing demand for e-vehicle maintenance and repairs.
“Working with Paul was amazing,” says Jonathan. “He worked really hard with the demanding list of resources and budget I gave him and created a workspace which used that achieved the best outcome possible.”
“We needed a company which could help realize our aspirational design for a new and targeted curriculum, using the most up to date resources to enable our learners to develop and learn in the best way possible.
“This will give them an advantage when going out into industry with the ability to carry out practices which currently skilled technicians may not be familiar with, giving them a competitive edge above other potential candidates.
“Using quality equipment and top-notch technology helps our learners to go further and faster, setting them apart from the rest and giving them the best chance of enjoying a successful future.”
Yeovil College is an exceptionally high-performing further education college, achieving an annual turnover of over £20 million, increased from £12 million over the past seven years.
The college is pursuing the highest possible ambitions for its students and for the wider community, sharing the mission that ‘only our best is good enough.’
Jonathan added: “With our eyes firmly on the future of our region, we are focused on improving opportunities across South Somerset and North and West Dorset. Our relentless approach is having a huge impact; we are changing the lives of the people around us.”
Company Profile
Since 1920 Snap-on Industrial has been a world leading tooling solutions specialist with unrivalled expertise in providing bespoke solutions across a diverse range of industry sectors, which include natural resources, defence, aviation, construction, as well as manufacturing, rail and food production.
Snap-on Industrial provides companies with strategic advantages in addressing the challenge of increasing profitability, through reduced downtime, increased productivity and cost control.
Snap-on Industrial at AERO Friedrichshafen 2024
Snap-on Industrial at
AERO Friedrichshafen 2024
17th - 20th April 2024 | Hall A5 | Stand 123 | Friedrichshafen, Germany
Serving the critical industries since 1920, Snap-on Industrial designs and supplies products and services to their customers, including hand & power tools, tool storage, tool control, information & management systems and other solutions for aviation & aerospace, government & military, rail, energy and education.
Come and see us on stand at the AERO Friedrichshafen 2024 exhibition in Germany. We will be showcasing our Level 5 tool management system and torque products as well as various other tools especially picked out for Aviation.
About the event
The world‘s leading trade show for general aviation celebrates its 30th anniversary this year.
Discover what direction developments in the General Aviation industry are going at the AERO Friedrichshafen. With more than 600 exhibitors from 35 countries, 33,000 visitors and 600 journalists from all over the world, the AERO Friedrichshafen is the international community’s annual meeting place.
AERO Friedrichshafen 2024 | The Leading Show for General Aviation.
AERO Friedrichshafen information
Exhibitor: Snap-on Industrial
Hall A5
Stand 123
17th – 20th April 2024
Friedrichshafen, Germany
9 am – 6 pm
